TMC Cancela TDE-250 Right Hand Offset Rear Mtd. Mulching Topper

Features

• Body built in high strength steel
• Three point linkage with parallelogram device for displacement and with a mechanical safety device
• Front chain protection
• Float device on 3-point linkage to control ground adjustment as well as impacts during transport
• Pneumatic shock-absorber for deployment
• Internal rear roller for height adjustment with protection skids
• Rotor with floating hammers assembled to the rotor with 27mm diameter bolts – Boltop system
• External gearbox with freewheel and drive shaft of 1. 3/4" Z6
• Transmission with 6 belts
• Input of 540 rpm, optional 1,000 rpm by inversion of pulleys
• Fully CE marked & 1 year manufacturers warranty

Working width (m) 2.5

Total width (m) 3.23

Required input power (cv) 140

Max. allowed power (cv) 200

Rotor/s cutting diameter (mm) 485

Gearbox input speed (rpm) 540 (optional 1,000)

No. of hammers (A18) 26

Counterblades 2 replaceable rows +1 fixed row

Linkage category Cat. 2 No. of belts – type 6 – XPB

Skids Bolted (fixed position)

Adjustable height control Rear Roller

PTO shaft Bondioli type 108

Weight (kg) 1,255

Hydraulic cylinder stroke (mm) 253 / 205

Working reach Hydraulic (mm) 409.5–3,660.5
